ATMEGA32-16PU

80 INR

Get a Price/Quote

Product Details:

Processor Speed 16 MHz Max
Operating Temperature -40C to +85C
Input Digital/Analog Inputs via GPIO
Features High-Performance, Low-Power, 32 KB Flash, 2 KB SRAM, 1 KB EEPROM, 32 Programmable I/O Lines, External/Internal Interrupts
Components 40 Pins, Integrated Peripherals
Usage Embedded Systems, Electronic Projects
Power Source DC Supply
Click to View more

Request to Call Back Send Inquiry

Product Details
Product Description

ATMEGA32-16PU Price And Quantity

Price 80 INR
Price Range 80.00 - 110.00 INR
Minimum Order Quantity 10 Piece

ATMEGA32-16PU Product Specifications

Response Time Instantaneous
Thickness Standard DIP-40 Package
Dimension (L*W*H) Approx. 52.5mm x 13.2mm x 4.6mm
Current Rating Operating up to 40mA per I/O pin
Rated Voltage 5V DC
Supply Voltage 4.5V to 5.5V
Output Digital/Analog Outputs via GPIO
Interface UART, SPI, I2C, GPIO
Power Supply 5V DC
Usage Embedded Systems, Electronic Projects
Components 40 Pins, Integrated Peripherals
Size DIP-40 Form Factor
Power Source DC Supply
Features High-Performance, Low-Power, 32 KB Flash, 2 KB SRAM, 1 KB EEPROM, 32 Programmable I/O Lines, External/Internal Interrupts
Input Digital/Analog Inputs via GPIO
Color Black
Operating Temperature -40C to +85C
Frequency 16 MHz
Application Industrial, Consumer, Robotics, Automation
Weight Approx. 5g
Processor Speed 16 MHz Max
Capacity 32 KB Flash Memory
Function 8-bit AVR Microcontroller
Product Type Microcontroller IC

ATMEGA32-16PU Trade Information

Main Domestic Market All India

Product Description

Specification

Base Part Number	ATMEGA162
RAM Size	1K x 8
Speed	16MHz
Voltage Supply	2.7 V ~ 5.5 V (Vcc/Vdd)
Supplier Device Package	40-PDIP
Program Memory Type	Flash
Program Memory Size	16KB (8K x 16)
Peripherals	Brown-out Detect/Reset, POR, PWM, WDT
Part Status	Obsolete
Packaging	Tube
Package Case	40-DIP (0.600", 15.24mm)
Oscillator Type	Internal
Operating Temperature	-40 deg C ~ 85 deg C (TA)
Number of IOs	35 I/O
EEPROM Size	512 x 8
Core Size	8-Bit
Core Processor	AVR
Connectivity	EBI/EMI, SPI, UART/USART

High-Performance Architecture

The ATMEGA32-16PU boasts a powerful 8-bit AVR RISC architecture optimized for fast instruction execution and efficient code. Designed for demanding real-time applications, its 16 MHz maximum frequency ensures responsive performance, making it a trusted choice for complex embedded systems.

Comprehensive Peripheral Integration

This microcontroller features a broad range of integrated peripherals, including three timers/counters, a 4-channel PWM, and an 8-channel, 10-bit analog-to-digital converter. Such versatility supports advanced automation, data acquisition, motor control, and sensor interfacing applications with ease.

Robust Memory and Data Retention

Equipped with 32 KB Flash, 2 KB SRAM, and 1 KB EEPROM, the ATMEGA32-16PU enables reliable program and data storage. Its Flash/EEPROM memory offers impressive data retention of up to 100 years at 25C, ensuring long-term reliability even in demanding environments.

FAQs of ATMEGA32-16PU:

Q: How can the ATMEGA32-16PU be programmed in embedded projects?

A: The ATMEGA32-16PU can be programmed using the SPI In-System Programming interface, allowing for easy code uploads and updates without removing the microcontroller from the circuit. Compatible development tools and programming environments are widely available for seamless integration.

Q: What types of applications benefit most from the ATMEGA32-16PU?

A: This microcontroller is particularly effective in areas like industrial automation, robotics, consumer electronics, and embedded control systems, owing to its extensive I/O capabilities, analog/digital interfacing, and robust memory resources.

Q: When is it advisable to use the ATMEGA32-16PU over other microcontrollers?

A: It is ideal when your project demands high reliability, ample I/O pins, a mix of analog and digital interfacing, and flexible programming, along with long data retention and a predictable operating temperature range from -40C to +85C.

Q: Where can I purchase the ATMEGA32-16PU in India?

A: The ATMEGA32-16PU is widely available through distributors, importers, manufacturers, suppliers, traders, and wholesalers across India. Online electronic component retailers and local electronics markets are also reliable sources.

Q: What is the process to interface sensors and actuators with this microcontroller?

A: Sensors and actuators can be connected via the 32 programmable I/O pins, utilizing the 8-channel ADC for analog sensors and PWM outputs for actuators. The device supports standard communication interfaces like UART, SPI, and I2C for more advanced connectivity needs.

Q: What are the primary benefits of using the ATMEGA32-16PU for developers?

A: Developers gain the advantages of high processing speed, multiple operating modes for power efficiency, extensive memory, programmable peripherals, and reliable operation over a wide temperature range, making design and implementation straightforward.
